VIMS Isolator

FeaturesVIMS clip small

  • Floor or roof mount
  • Equipment with fluctuating operating weights
  • Standard (VIMS) or High Capacity (VIMS-S)
  • Integrated seismic and wind restraints
  • 1″ or 2″ deflection

About the VIMS Isolator

The VIMS isolator is VIB-ISO’s standard roof curb or floor-mount isolator ideal for equipment with fluctuating operating weights. It is avilable in standard, VIMS, or high, VIMS-S, capacity. Designed to integrate with any roof curb or floor-mounted piece of equipment, the VIMS isolator will aid to reduce the vibration from large mechanical and electrical equipment to the building structure. The VIMS has integrated lateral and vertical restraints in order to account for seismic and wind loads. Additionally, the channel design of the VIMS housing accounts for additional seismic load capacity.

VIB-ISO will engineer each VIMS isolator to match your specified unit and meet any additional customer requirements. The VIMS isolator is available in either 1” or 2”deflection and is shipped fully assembled with the springs and restraints installed at VIB-ISO in order to reduce onsite labor requirements. The springs are made of structural steel and sit on an elastomeric mount. The housing is made entirely of structural steel. On site, the VIMS design allows for quick assembly requiring only basic tools for installation.

Additional Information

VIMS Product Data Sheet
VIMS-S Product Data Sheet
VIMS(S) Installation Instructions
